Volkwagon CC 1979 Fuse Box/Block Circuit Breaker Diagram

Volkwagon CC 1979 Fuse Box/Block Circuit Breaker Diagram



SYMBOLAMPSFUSE MAP
18ATurn Signals Speedometer Warning Lights Fuel Gauge
28AWindshield Wipers Brake Warning Light Automatic Stick Shift Warning Lights Rear Window Defroster Switch
38ABrake Lights, Horn
48AEmergency Flasher
58AUnassigned
68AInterior Light, Ignition Buzzer
78ALeft High Beam, High Beam Warning Light
88ARight High Beam
916ALeft Low Beam
108ARight Low Beam
1116ALeft Tail Light
128ARight Tail Light, side Marker Lights, License Plate Light

Volkwagon CC 1979 Fuse Panel/Board – Fuse Symbol Map
