Tata Indigo Near Fire Wall CR-4 Fuse Box / Block Circuit Breaker

Categories:

Fuse Box Diagram, Tata

by Pad Rust

Tata Indigo Near Fire Wall CR-4 Fuse Box / Block Circuit Breaker
Tata Indigo Near Fire Wall CR-4 Fuse Box / Block Circuit Breaker

Fuse MapA
Radiator Fan40A
Fan Relay Coil5A
ECU Power Relay15A
ABS Motor40A
ABS Valves20A
ECU Diode Module5A

Tata Indigo Near Fire Wall CR-4 Fuse Panel / Board – Fuse Symbol Map
