Mazda MX6 1995 Main Fuse Box/Block Circuit Breaker Diagram
| NO. | CIRCUIT NAME | FUSE |
|---|---|---|
| 1 | POWER WINDOW | 30A |
| 2 | STOP or HORN | 15A |
| 3 | ENGINE | 15A |
| 4 | HAZARD | 15A |
| 5 | METER | 10A |
| 6 | REAR WINDOW DEFROSTER | 20A |
| 7 | TAIL | 15A |
| 8 | AUDIO | 15A |
| 9 | Not Used | - |
| 10 | Not Used | - |
| 11 | DOOR LOCK | 30A |
| 12 | ROOM | 10A |
| 13 | AIR CONDITIONER | 15A |
| 14 | CENTER DIF-LOCK | 20A |
| 15 | SUNROOF | 15A |
| 16 | WIPER | 15A |
| 17 | COOLING FAN | 20A |
| 18 | REAR WIPER | 10A |
Mazda MX6 1995 Main Fuse Panel/Board – Fuse Symbol Map
