Lexus CT200H 2011 Fuse Box/Block Circuit Breaker Diagram
| Fuse Symbol | Fuse Map | Amps |
|---|---|---|
| 1. | RR DEF | 40A |
| 2. | AM1 | 40A |
| 3. | D FR P/W | 20A |
| 4. | Tail | 10A |
| 5. | GAUGE | 10A |
| 6. | DOOR | 20A |
| 7. | PANEL | 7.5A |
| 8. | WASHER | 15A |
| 9. | STARTER | 7.5A |
| 10. | FR DEF | 20A |
| 11. | A/C | 10A |
| 12. | SEAT HTR | 15A |
| 13. | CIG | 15A |
| 14. | S/ROOF | 30A |
| 15. | ECU-IG | 10A |
| 16. | SRS-ACC | 10A |
| 17. | STOP | 15A |
| 18. | WIPER | 25A |
| 19. | RADIO NO.2 | 10A |
| 20. | - | - |
Lexus CT200H 2011 Fuse Panel/Board – Fuse Symbol Map
