Cadillac XLR 2004 Main Fuse Box/Block Circuit Breaker Diagram
| SYMBOL | FUSE MAP | AMPS |
|---|---|---|
| MINI FUSES | ||
| MINI-FUSIBLES | ||
| 1 | EXH VLV | 30A |
| 2 | ESC/ALC EXH | 30A |
| 3 | TRLR STOP LT | 10A |
| 4 | ENG | 15A |
| 5 | ECM/THROT CONT | 15A |
| 6 | TRLR STOP RT | 10A |
| 7 | FRT WASH | 15A |
| 8 | 02 B SNSR | 10A |
| 9 | ABS 2 | 25A |
| 10 | TRLR BCK/UP | 10A |
| 11 | LO HDLP-LT | 20A |
| 12 | ECM-BATT | 10A |
| 13 | INJ-B | 20A |
| 14 | TCM-BATT | 10A |
| 15 | VEH BCK/UP | 10A |
| 16 | LO HDLP-RT | 20A |
| 17 | A/C COMPRSR | 10A |
| 18 | 02-A SNSR | 10A |
| 19 | TRANS IGN 1 | 15A |
| 20 | FUEL PUMP | 20A |
| 21 | HEADLAMP WASH | 20A |
| 22 | REAR WASH | 15A |
| 23 | INJ-A | 20A |
| 24 | TRLR PRK | 15A |
| 25 | LT PRK | 15A |
| 26 | RT PRK | 15A |
| 27 | FOG LAMP | 15A |
| 28 | HORN | 15A |
| 29 | HI HEADLAMP-RT | 10A |
| 30 | DRL | 15A |
| 31 | HI HEADLAMP-LT | 10A |
| 32 | DRL 2 | 15A |
| 33 | S/ROOF | 30A |
| 34 | DLIS | 2A |
| 35 | WPR | 25A |
| 36 | SEO B2 | 30A |
| 37 | EAP | 15A |
| 38 | HVAC BATT | 10A |
| 39 | AIRBAG IGN | 10A |
| 40 | AMP | 30A |
| 41 | RDO | 15A |
| 42 | FWD | 15A |
| 43 | MISC IGN | 10A |
| 44 | L/GATE RELSE | 15A |
| 45 | INFO | 15A |
| 46 | IPC | 10A |
| 47 | EXP/PTO | 15A |
| 48 | HTD STR/WHL | 10A |
| 49 | AUX HVAC-IGN | 10A |
| 50 | REAR DEFOG | 30A |
| 51 | AIRBAG BATT | 15A |
| 52 | SEO B1 | 15A |
| 53 | LTR | 20A |
| 54 | SEO/ALC | 10A |
| 55 | HVAC-IGN | 10A |
| 56 | ECM-IGN | 15A |
| J-CASE FUSES | ||
| FUSIBLES JCASE | ||
| 60 | FAN-1 | 40A |
| 61 | ALC/COMP | 40A |
| 62 | HEAVY DUTY ABS | 60A |
| 63 | FAN-2 | 40A |
| 64 | ABS-1 | 40A |
| 65 | STRTR | 40A |
| 66 | STUD-2 | 30A |
| 67 | LBEC1 | 60A |
| 68 | ELEC RUN BOARD | 30A |
| 69 | WFHS | 60A |
| 70 | TREC | 30A |
| 71 | STUD-1 | 40A |
| 72 | MBEC1 | 60A |
| 73 | HVAC BLWR | 40A |
| 74 | LGM | 30A |
| 75 | LBEC2 | 60A |
Cadillac XLR 2004 Main Fuse Panel/Board – Fuse Symbol Map
