Cadillac CTS 2011 Compartment Fuse Box/Block Circuit Breaker Diagram
| FUSE | USAGE |
|---|---|
| FUSES | |
| FUEL/DR/RELSE | Not Used |
| LCK | Lock |
| LT/POS/LP | Left Position Lamp |
| MRKR/LP | Not Used |
| REAR/FOG | Not Used |
| RT/POS/LP | Not Used |
| STOP/LP | Not Used |
| TRUNK/RELSE | Trunk Release |
| UNLCK | Unlock |
| MINI FUSES | |
| AIRBAG | Airbag System |
| AMP | Amplifier |
| AUX/OUTLET | Auxiliary Power Outlet |
| CNSTR/VENT | Canister Vent |
| DR/LCK | Door Lock |
| ECM | Engine Control Module (ECM) |
| FUEL/PUMP | Fuel Pump |
| LT/POS/LP | Left Position Lamp |
| MSM | Memory Seat Module |
| ONSTAR | Onstar System |
| PDM | Passenger Door Module |
| RDO | Audio System |
| RDO/SPKR | Audio Speakers |
| REAR/FOG | Not Used |
| REAR/WSW | Rear Windshield Wiper/Washer |
| RKE/PASSKEY/MDL | Remote Keyless Entry System, Pass-key Theft Deterrent Feature Module |
| RT/POS/LP | Not Used |
| RT/POS/LP | Right Position Lamp |
| RVC/SNSR | Regulated Voltage Control Sensor |
| S/ROOF | Sunroof |
| STOP/LP | Not Used |
| THEFT/UGDO | Theft Deterrent System, Universal Home Remote System |
| TRLR/POS/LP | Trailer Turn Position Lamps |
| WASH/PUMP | Windshield Washer Pump |
Cadillac CTS 2011 Compartment Fuse Panel/Board – Fuse Symbol Map
